PRODUCT CHARATERISTICS
Code | FGV-VL-04-02 |
Size (mm) | 1800mm (L) * 1400mm (W) * 1200mm (H) |
Weight (kg) | 140kg (not including hoist cylinder) |
Driven System | Pneumatic Components Integration |
Suction Cup | Round sucker; NBR material; oil & abrasion resistance; suction 350kgf; location adjustable; with buffer spring for height compensation |
No. & Size of Cups | 4 pads; 300mm diameter |
Structure | L type; steel material; ergonomic design |
Min. Glass Size | 1000mm (L) x 1000mm (W) |
Max.Glass Size | 4000mm (L) x 2400mm (W) |
Safety Loading Weight | 500kg |
Lifting Material | Glass, marble, plastic boards, metal sheets, coated boards and other plates. |
Usage | Gripping, lifting and handling in the glass production and processing line, and glass packaging. |
Installation Request | Hanged on the pillar jib crane or frame crane or bridge crane; compressor power supply |
Packaging | Plywood Case |
Delivery Time | Within 20 days after receiving the payments |
Payment terms | L/C, T/T |
MOQ | 1 set |
Supply ability | 500 sets per month |
Certificate | CE, SGS |
Others | OEM / ODM accepted |
3. PRODUCT TECHNIQUE
Safety Loading Weight | 500 kg |
Factor of Safety | 2.5 |
Standard Working Power | 0.6~0.8 mpa |
Noise Level | < 60 Db |
Vacuum Holding time | More than 30 minutes after power loss |
Gripping | Suction cups in vacuum state |
Hoist Cylinder | 100mm diameter; 1200mm distance; universal connection; three position five way valve make cylinder stay at any height with no drop, even if power loss |
Rotation | Turn up to 90 degree driven by cylinder |
Safety Protection | Vacuum non-return system and vacuum compensation system |
Vacuum Compensation | when vacuum reaches to the specified pressure, it automatically closes the compressed air supply, to achieve energy saving; when vacuum pressure is insufficient, it automatically restore compressed air supply, to achieve vacuum compensation. |
Control Method | Color-different buttons control on the same panel |
