Технические характеристики :
project | unit | specifications | |
capacity | Max. roating diameter | mm(in) | Φ870(34.25) |
Appron roating diameter | mm(in) | Φ700(27.56) | |
Max. working length | mm(in) | 450(17.7) | |
Max. diameter of wheel hub | Inch | 26″(610mm) | |
Max. height of wheel hub | Inch | 14″(356mm) | |
principle axis | Hydraulic chuck diameter | Inch | Zhong shi 21″
(select configuration) |
Mode of spindle head | A2-11 | ||
Diameter of spindle bearing | mm(in) | 180/160(front /back) | |
Spindle speed | rpm(rpm) | 20-2000 | |
Spindle power | Kw(hp) | 45/55(33/40.5) | |
apron | route(X1X2/Z1Z2) | mm(in) | 520/550(20.47/21.65) |
Rapid speed(X1X2/Z1Z2) | m/min(ipm) | 24/24(945/945) | |
servo motor(X1X2/Z1Z2) | α30i/α30i | ||
Servo motor torsion feed system(X1X2/Z1Z2) | N m(ft-lb) | 30/30(40.65/40.65) | |
Servo motor power(X1X2/Z1Z2) | kW(hp) | 7/7(5.14/5.14) | |
Ball screw diameter guide
(X1X2/Z1Z2) |
mm(in) | Φ50×8/Φ50×8
(2 x0.315/2 x0.315) |
|
tool rest | stations | .
Horizontal 6 station servo. |
|
Tool size (turning/boring) | mm(in) | 32×32/Φ50(1.25X1.25/2) | |
others | power | kVA | 85 |
Volumn ((L×W×H)) | mm(in) | 3400X4700X3365
(133.86X185.047X132.48) |
|
Main machine net weight/total weight
· · |
Kg(lbs) | about16000/17000(about 35208/37485) |
