Технические характеристики :
Model | BYK60100 | |
Maximum planing length (mm) | 1000 | |
The maximum lateral movement distance of the worktable (mm) | 800 | |
The maximum distance from the bottom of the ram to the worktable (mm) | 400 | |
The maximum vertical movement distance of the worktable (mm) | 380 | |
Dimension of working surface of worktable (length×width) (mm) | 1000×500 | |
Turret stroke (mm) | 160 | |
Maximum turning angle of tool post (°) | ±60° | |
Maximum size of planer handle (width×thickness) (mm) | 30×45 | |
The number of reciprocating rams per minute | 15、20、29、42、58、83 | |
Range of table motorized feed | Horizontal feed level 10 (mm) | 0.3~3 |
Vertical feed 8 levels (mm) | 0.15~0.5 | |
Fast moving speed of worktable | Horizontal feed (mm) | 3 |
Vertical feed (mm/min) | 0.5 | |
T-slot size in the center of the worktable (mm) | 22 | |
Main motor power (kw) | 7.50 | |
Dimension (length×width×height) (mm) | 3640×1575×1780 | |
Net weight/Gross weight (kg) | 4870/5150 |
